Main Specification
General | 1 | Manufacturing | - | UN | ||||
---|---|---|---|---|---|---|---|---|
2 | Model | - | FD30T | |||||
3 | Power Type | - | Diesel | |||||
4 | Rate Load Capicity | Q(Kg) | 3000 | |||||
5 | Load Centre | C(Mm) | 500 | |||||
Charateristic & Dimension | 6 | Rated Lift Height | H3(mm) | 3000 | ||||
7 | Free Lift Height | H2(mm) | 100 | |||||
8 | Fork Size (L*W*T) | mm | 1070x125x45 | |||||
9 | Mast Tilt Angle(F/R,a°/β°) | deg | 6°/12° | |||||
10 | Fork Overhang (Wheel Center to Fork Face) | X1(mm) | 484 | |||||
11 | Rear Overhang | X2(mm) | 595 | |||||
12 | Ground Clearance (Bottom of Mast) | H7(mm) | 145 | |||||
13 | Length to Face of Fork (Without Fork) | L1(mm) | 2700 | |||||
14 | Overall Width | B1(mm) | 1225 | |||||
15 | Mast Lowered Height | H1(mm) | 2070 | |||||
16 | Mast Extended Height (With Backrest) | H4(mm) | 4070 | |||||
17 | Overhead Guard Height | H5(mm) | 2235 | |||||
18 | Turning Radius (Outside) | Wa(mm) | 2425 | |||||
19 | Min Aisle width for pallets | mm | 4180 | |||||
Performance | 20 | Travel Speed (No Load) | km/h | 19 | ||||
21 | Lifting Speed (Full Load) | mm/sec | 430 | |||||
22 | Lowering Speed (Full Load) | mm/sec | 450 | |||||
23 | Max. Drawbar Pull (Full Load/No Load) | KN | 16(15.7) | |||||
24 | Max. Gradeabillity (Full Load) | % | 20 | |||||
Tyre | 25 | Tyre (Front x 2) | mm | 28x9-15-12PR | ||||
26 | Tyre (Rear x 2) | mm | 6.50-10-10PR | |||||
Weight | 27 | Total Weight | kg | 4460 | ||||
28 | Front Axle Weight Distribution (Full Load) | kg | 6714 | |||||
29 | Rear Axle Weight Distribution (Full Load) | kg | 746 | |||||
30 | Front Axle Weight Distribution (No Load) | kg | 1784 | |||||
31 | Rear Axle Weight Distribution (No Load) | kg | 2676 | |||||
Power & Transmission | 32 | Battery | V/Ah | 12/90 | ||||
33 | Fuel Tank Capacity | L | 50 | |||||
34 | Operating Pressure (For Attachments) | Mpa | 17,5 |
Main Specification
General | 1 | Manufacturing | - | UN |
---|---|---|---|---|
2 | Model | - | FD100T | |
3 | Power Type | - | Diesel | |
4 | Rate Load Capicity | Q(Kg) | 10000 | |
5 | Load Centre | C(Mm) | 600 | |
Charateristic & Dimension | 6 | Rated Lift Height | H3(mm) | 3000 |
7 | Free Lift Height | H2(mm) | 120 | |
8 | Fork Size (L*W*T) | mm | 1220x175x80 | |
9 | Mast Tilt Angle(F/R,a°/β°) | deg | 6°/12° | |
10 | Fork Overhang (Wheel Center to Fork Face) | X1(mm) | 721 | |
11 | Rear Overhang | X2(mm) | 760 | |
12 | Ground Clearance (Bottom of Mast) | H7(mm) | 250 | |
13 | Length to Face of Fork (Without Fork) | L1(mm) | 4270 | |
14 | Overall Width | B1(mm) | 2166 | |
15 | Mast Lowered Height | H1(mm) | 2845 | |
16 | Mast Extended Height (With Backrest) | H4(mm) | 4260 | |
Performance | 17 | Overhead Guard Height | H5(mm) | 2540 |
18 | Turning Radius (Outside) | Wa(mm) | 4100 | |
19 | Min Aisle width for pallets | Asl(mm) | 6045 | |
20 | Travel Speed (No Load) | km/h | 19/16 | |
21 | Lifting Speed (No Load/Full Load) | mm/sec | 380/328 | |
22 | Lowering Speed (No Load/Full Load) | mm/sec | ≥300/≤600 | |
23 | Max. Drawbar Pull (Full Load) | KN | 57 | |
24 | Max. Gradeabillity (Full Load) | % | 20 | |
Chassis | 25 | Tyre (Front x 4) | mm | 9.00-20-14PR |
26 | Tyre (Rear x 2) | mm | 9.00-20-14PR | |
27 | Front Tread | mm | 1600 | |
28 | Rear Tread | mm | 1700 | |
29 | Wheelbase | Y(mm) | 2800 | |
Weight | 30 | Total Weight | - | 12900 |
31 | Front Axle Weight Distribution (Full Load) | - | 20610 | |
32 | Rear Axle Weight Distibution (Full Load) | - | 2290 | |
33 | Front Axle Distribution (No Load) | kg | 5660 | |
34 | Rear Axle Weight Distribution (No Load) | - | 8240 | |
Power & Transmission | 35 | Battery | V/Ah | 24/90 |
36 | Fuel Tank Capacity | L | 120 | |
37 | Transmission Type | - | Powershift | |
38 | Transmission Stage (FWD、RVS) | - | 02/02 | |
39 | Operating Pressure (For Attachments) | mpa | 20 |
